Cục đẩy công suất 4Acoustic SQ2404
Model Name | SQ-2404 |
GS1 (EAN) CODE | 4.26032E+12 |
System Type | 4-Channel Class H |
Output Power | 4 x 900W @ 4Ohm |
all channels driven | 4 x 600W @ 8Ohm |
20Hz - 20 kHz, 0.1 % THD |
|
Output Power | 2 x 2400W @ 4Ohm |
Bridge mode | 2 x 1800W @ 8Ohm |
| 2 x 1200W @16Ohm |
THD+N | ≤0.5% @ 8Ω 1kHz |
Slew Rate | >28V/μs |
Frequency Response | 10Hz - 20KHz / ±0.4dB |
@1Watt, 8Ohm | |
Damping Factor | >3000 @100Hz |
(1kHz and below) | |
Signal to Noise Ratio | >100dB |
20Hz -20 kHz | |
Channel Separation | >70dB |
Crosstalk@1kHz | |
Voltage Gain | 39dB (0,775V:69.5V) |
Input Sensitivity | selectable 0.775V/1V/1.4V |
Input Impedance | 20k Ohm Balanced, |
10k Ohm Unbalanced | |
Front Control | Power switch, Gain control |
Rear Control | Sensitivity Switch, |
Mode Switch | |
LED Indicators | Signal, Clip, Protect, |
Power, Bridge | |
Input Connectors | XLR Active balanced |
pin1 gnd / pin 2+ / pin3- | |
Output Connectors | 4 NL4 Sockets, 4xBinding Posts |
Cooling | Low Noise Continuously |
Variable speed fan | |
Protection | Full short circuit, Open circuit, |
thermal, Ultrasonic, | |
RF Protection. | |
Stable Into reactive or | |
Mismatched loads | |
Load Protection | On/Off muting, DC fault |
power Supply shutdown | |
Operating Voltage | 230V (+/- 10%), 50-60Hz |
USA Version 110V (+/- 10%), 50-60Hz | |
Fuse | T-20A |
Idle | < 30W |
Power Consumption | |
Max. | < 2000W |
Power Consumption | |
Dimensions (h/w/d) | 19“/2U 483mm×492mm×90mm |
Net weight | 25 kg |
